4" KUNMING R-4 CNC Horizontal Table Type Boring Mill, NEW
Manufacturer: KUNMING
Model: R-4
Asset Type: 47976
Year: 2024
Condition: used
Stock Number: 17534
Status: For Sale
used #17534
NEW, 4" MANUAL + FULL CNC HORIZONTAL BORING MILL
4.33" ISO 50 Spindle
20 HP Main Drive
70.8" × 55.1" × 63" Travels (X/Y/Z)
49.2" × 55.1" Rotary Table
11,000 lb Table Capacity
Integrated Facing Head
Full 360° B-Axis Table
2024 Model Year
Request Quote
4.33" ISO 50 Spindle
20 HP Main Drive
70.8" × 55.1" × 63" Travels (X/Y/Z)
49.2" × 55.1" Rotary Table
11,000 lb Table Capacity
Integrated Facing Head
Full 360° B-Axis Table
2024 Model Year
Specifications | |
|---|---|
| Distance | |
| Spindle Size | 4.33 in |
| X-Horiz Tvl of Table | 70.8 in |
| Y-Vert Tvl of Head | 55.1 in |
| Table-W | 49.2 in |
| Table-L | 55.1 in |
| Spindle Tvl. | 23.6 in |
| Mechanical power | |
| Power | 20.0 hp |
| Rotational speed | |
| RPM | 0.0 rpm |
