24" EMAG VMC 450-5MT Vertical Turning Center, 2021
Manufacturer: EMAG
Model: VMC 450-5MT
Asset Type: 73317
Year: 2021
Condition: used
Stock Number: 20540
Status: For Sale
used #20540
24" EMAG, 5 AXIS VERTICAL TURNING AND MILLING CENTER, VMC 450-5MT; UNUSED
Chuck Dia.: 24"
Capacity: 1100","pounds
Max Swing Diameter: 31"
Turning Diameter: 23.5"
X-Axis Travel (Upper/Lower): 30"
Z-Axis Travel (Upper/Lower): 19"
Drive Power: 100 HP (full power at 800 RPM)
Max Spindle Speed (RPM): 2000 RPM
Z-Axis Rapid Traverse Rate: 60/30 M/Min.
Feed Force X / Z: 4 / 15 kN
Ball Screw Diameter X / Z: 40 / 50 MM
Milling Spindle Motor: 100 HP
Max Milling Spindle Speed (RPM): 7000 RPM
Milling Spindle Taper: CAPTO C8
Tool Changer Capacity: 60
Request Quote
Chuck Dia.: 24"
Capacity: 1100","pounds
Max Swing Diameter: 31"
Turning Diameter: 23.5"
X-Axis Travel (Upper/Lower): 30"
Z-Axis Travel (Upper/Lower): 19"
Drive Power: 100 HP (full power at 800 RPM)
Max Spindle Speed (RPM): 2000 RPM
Z-Axis Rapid Traverse Rate: 60/30 M/Min.
Feed Force X / Z: 4 / 15 kN
Ball Screw Diameter X / Z: 40 / 50 MM
Milling Spindle Motor: 100 HP
Max Milling Spindle Speed (RPM): 7000 RPM
Milling Spindle Taper: CAPTO C8
Tool Changer Capacity: 60
Specifications | |
|---|---|
| Distance | |
| Table Dia | 24.0 in |
| Swing | 31.0 in |
| Max Diameter | 23.5 in |
| Travel-Cross | 30.0 in |
| Mechanical power | |
| Power | 100.0 hp |
| Rotational speed | |
| RPM | 2000.0 rpm |
